Strong up light Small size LED inground light IGLB2CAR0158 - IGLB2CAS0158

Strong up light Small size LED inground light IGLB2CAR0158 and IGLB2CAS0158
Housing: 12# Die-casting grey powder coated aluminum T=60-80um. Adhesion of ISO class 1/ASTM class 4B
Front cover: Hard chromeplated Stainless steel SUS 316L#
Light Window: Tempered frosted step glass.T=5mm
LED: NICHIA
Glass pressure capacity: Full area = 783kgs
Gasket: Molding shaped silicone seal
Led driver: Constant Voltage Input, Constant Current Output
Operating temperature: -20˚C ~ 40˚C
Power Cable: H05RN-F 2X 1.0mm2 L=0.5m (low voltage)
H05RN-F 3X 1.0mm2 L=0.5m (high voltage)
Mounting sleeve: ABS 014#
Dimmable Support: Triac, PWM, 1-10V, Dali
Certificattions: CE, RoHS
IP rate: IP67

Specifications:

Item	IGLB2CAR0158	IGLB2CAS0158
Light source	1 x 3W	1 x 3W
Lens	B33	B33D/B33F
The manufacturer selected lens degree (º) ϴ1/2	9º, 15º, 20º, 30º, 45º	9º, 15º, 20º, 30º, 45º
Input voltage (V)	24V DC 120/240	24V DC 120/240
Typical operating current (mA)	24V = 187 120V = 61 240V = 34	24V = 187 120V = 61 240V = 34
Typical consumption (W)	24V = 4.5 120V = 4.3 240V = 4.3	24V = 4.5 120V = 4.3 240V = 4.3
Typical luminance (lm)	Cool white = 305 Warm white = 267	Cool white = 305 Warm white = 267
IP rate	IP67	IP67
IK rate	08	08
