Đèn âm đất mini, đèn âm đất góc chiếu thẳng, đèn âm đất góc chiếu đứng, up beam type inground light, mini led inground light, up light led

SKU: IGLB2WDR0157A - IGLB2WDS0157A

Strong up light power LED inground light IGLB2WDR0157 A - IGLB2WDS0157 A

Strong up light power LED inground light IGLB2WDR0157 A - IGLB2WDS0157 A
Housing: 12# Die-casting grey powder coated aluminum T=60-80um. Adhesion of ISO class 1/ASTM class 4B
Front cover: Hard chromeplated Stainless steel SUS 316L#
Light Window: Tempered frosted step glass.T=7mm
LED: OSRAM
Glass pressure capacity: Full area = 1704kgs
Gasket: Molding shaped silicone seal
Lens: Optical lens effeciency ≥85%
Operating temperature: -20˚C ~ 40˚C
Power Cable: H05RN-F 2X 1.0mm2 L=0.5m (low voltage)
H05RN-F 3X 1.0mm2 L=0.5m (high voltage)
Mounting sleeve: ABS 011#
Dimmable Support: Triac, PWM, 1-10V, Dali
Certificattions: CE, RoHS
IP rate: IP67

Specifications:

Item	IGLB2WDR0157 A	IGLB2WDS0157 A
Light source	1 x 2W	1 x 2W
Lens	B33D/B33F	B33D/B33F
The manufacturer selected lens degree (º) ϴ1/2	9º, 15º, 20º, 30º, 45º	9º, 15º, 20º, 30º, 45º
Input voltage (V)	24V DC 120/240	24V DC 120/240
Typical operating current (mA)	24V = 105 120V = 47 240V = 28	24V = 105 120V = 47 240V = 28
Typical consumption (W)	24V = 2.5 120V = 3.0 240V = 3.1	24V = 2.5 120V = 3.0 240V = 3.1
Typical luminance (lm)	Cool white = 183 Warm white = 143	Cool white = 183 Warm white = 143
IP rate	IP67	IP67
IK rate	08	08
