Underwater LED Spot Light USLB5TL0657
Color temperature:
2000K
3000K
6000K
Housing: Hard chrome-plated molding shaped stainless steel SUS 316L#
Front cover: Hard chrome-plated stainless steel SUS 316L#
Light window: Step tempered glass T=5mm
LED: OSRAM or NICHIA
Lens: Separate optical lens efficiency ≥ 85%
Bracket: Hard chrome-plated molding shaped stainless steel SUS 316L#
PCB: Excellent heat conductivity aluminum, coefficient of heat conductivity ≥ 2.0w/mk
LED Driver: Constant Voltage Input, Constant Current Output
Cable gland: IP68 PG-11 copper with nickel coated
Seal: Molding shaped silicone seal under the front cover silicon glue among LED, lens and PCB
Power Cable: H07RN-F 2X1.0mm2 L=3.0m
Built-in Overheat Sensor system: Automatic shutdown at 75ºC
Application environment: Temperature of water between -20˚C~40˚C less than 1 meter depth.
Dimmable support: Triac, PWM, 1-10V, Dali
Certifications: CE, RoHS
IP rate: IP68
Beam angle: 8º, 13º, 25º, 30º
