SKU: IGLD2RLB4834 - IGLD2RLB9634
| Item | IGLD2RLB4834 | IGLD2RLB9634 |
|---|---|---|
| Light source | 48 x 0.3 NICHIA | 96 x 0.3 NICHIA |
| Length L = (mm) | 549 | 1025 |
| The manufacturer selected lens degree (º) ϴ1/2 | 120º | 120º |
| Input voltage (V) | 24V DC 120/240 |
24V DC 120/240 |
| Typical operating current (mA) | 24V = 555 120V = 106 240V = 60 |
24V = 1108 120V = 212 240V = 107 |
| Typical consumption (W) | 24V = 13.2 120V = 12.5 240V = 13.0 |
24V = 26.5 120V = 24.0 240V = 24.5 |
| Typical luminance (lm) | Cool white = 300 Warm white = 274 |
Cool white = 602 Warm white = 545 |
| IP rate | IP67 | IP67 |
| IK rate | 07 | 07 |
