High luminance output LED linear wall washer WAWB6P1657 - WAWB6P3057
Color temperature:
2000K
3000K
6000K
Housing: Extruded aluminum, powder coated
Lens: Optical lens efficiency ≥ 85%
Light window: Step tempered glass T=4mm
LED: OSRAM
Cable gland: IP68 PG-11 PA66
Gasket: IP68 plug male/female (option)
Bracket: Stainless steel T=1.5mm
Operating temperature: -20˚C~40˚C
Power Cable: Input: waterproof plug connector
Output: waterproof socket connector
2xH05RN-F 2X1.5mm2 L= 0.3m (low voltage)
2xH05RN-F 3X1.0mm2 L= 1.0m (high voltage)
Dimmable support: Triac, PWM, 1-10V, Dali
Certifications: CE, RoHS
IP rate: IP66
Beam angle: 15º, 20º, 30º, 45º
