Đèn rọi kiến trúc và cảnh quan, đèn chiếu kiến trúc và đèn chiếu cảnh quan, architectural and landscape spot light, đèn kiến trúc

SKU: SPLR3BJM0176-SPLR3CJM0171-SPLR3DJM0169-SPLR3EJM012

Architectural and Landscape Spot light SPLR3BJM0176 - SPLR3CJM0171 - SPLR3DJM0169 - SPLR3EJM0126

Architectural and Landscape Spot light SPLR3BJM0176 - SPLR3CJM0171 - SPLR3DJM0169 - SPLR3EJM0126
Color temperature:
   3000K
   6000K
Housing: 12# Die-casting dark grey powder coated aluminum T=60-80um. Adhesion of ISO class 1/ASTM class 4B
Light window: Tempered glass.T=3mm
Reflector: Optical reflector efficiency ≥ 90%
LED: NICHIA
Cable gland: IP68 PG-9 PA66
Gasket: Tooling shaped seal
LED Driver: Constant voltage input, Constant current output
Power Cable: H05RN-F 2X1.0mm2 L=0.3m (low voltage)
                      H05RN-F 3X1.0mm2 L=0.3m (high voltage)
Operating temperature: -20˚C~40˚C
Certifications: CE, RoHS
IP rate: IP66

Specifications:

Item	SPLR3BJM0176	SPLR3CJM0171	SPLR3DJM0169	SPLR3EJM0126
Light source	1 x 40W COB	1 x 20W COB	1 x 16W COB	1 x 6W COB
Lens	R16	R19	R17	R8
The manufacturer selected lens degree (º) ϴ1/2	12º, 25º, 38º	10º, 22º, 38º	12º, 18º, 32º	15º, 24º, 38º, 60º
Input voltage (V)	120/240V	24V DC 120/240V	24V DC 120/240V	24V DC 120/240V
Typical operating current (mA)	120V = 372 240V = 187	24V = 960 120V = 205 240V = 108	24V = 700 120V = 145 240V = 80	24V = 320 120V = 65 240V = 37
Typical consumption (W)	120V = 44.8 240V = 44.5	24V - 23.0 120V = 23.5 240V = 24.2	24V = 17.0 120V = 17.0 240V = 17.0	24V = 7.5 120V = 7.7 240V = 7.8
Typical luminance (lm)	Cool white = 3338 Warm white = 2949	Cool white = 1753 Warm white = 1543	Cool white = 1315 Warm white = 1225	Cool white = 730 Warm white = 646
IP rate	IP66	IP66	IP66	IP66
IK rate	06	06	06	05
